Combination scale automatic packaging machine
- Model
- DBW-EA series
Item specifics
- Component1
- material hoist
- Component2
- automatic weighing and counting machine (combination scale)
- Component4
- packaging machine
- Component5
- finished product conveyor
Review
Description
Parameter
DBW-EA series packaging and checkweighing combined system
Packaging speed
|
15-60 bags/min
|
||
Bag size
|
L:50- 300mm W:80- 200mm
|
||
Bag type
|
pillow bag, stand up pouch,pillow with hole pouch,continuous bag
|
||
Measuring range
|
150- 1500ml
|
||
Max film width | 420mm | ||
Film thickness | 0.04-0.10mm | ||
Air comsumption | 0.4m3/min 0.6MPa | ||
Packaging materia | PP/CPP、OPP/CE. MST/PE. PET/PEO | ||
Power source | 2. 5KW/220V 50-6 60Hz | ||
Overall size | L3560xW1940xH3200mm | ||
Weight | 1 800kg |
Products detail
Advantage:
Features
1.Application: candy, melon seeds, potato chips, pistachio nuts, peanuts, jelly, frozen dumplings, biscuits,chocolate, nuts, pet food, puffed food, small hardware, plastic parts, such as various granular, flaky, strip,irregular shape of the material quantitative weighing.
2.Servo film system, accurate positioning,excellent performance of the whole machine, beautiful packaging;Perfect automatic alarm protection function, reduce the loss to the minimum;
3.The machine and metering device can automatically complete the measurement, feeding, illing bag, date printing of all packaging process.
Application example
Applicable products:
Tea, coffee, frozen products, candies, melon seeds, potato chips, pistachios, peanuts, corn, wheat, nuts, preserved fruits.
Applicable products:
Jelly, frozen glutinous rice balls, biscuits, candied fruit, mothballs, raisins, almonds, chocolate, nuts, cereals, pet food.
Applicable products:
Quantitative weighing of various granular, flake, strip and irregular shaped materials such as puffed food, small hardware parts, plastic parts.
