High speed check weigher with rejector

Model: DCW series

Item specifics

Weight checking accuracy: Weight checking accuracy

Material: Weighing Sensor: Aluminum and stainless steel optional Roller: Aluminum Structure: stainless steel 304 Conveyor Belt: White, Food Grade, Polyurethane Thermoplastic (TPU)

Review

Description

Parameter

DCW series High precision checkweigher

Product model	DCW3012L02	DCW3512L05	DCW4012L1
Display scale	0.02g	0.05g	0.1g
Weight checking range	1-200g	1- 500g	2-1000g
Weight checking accuracy	± 0.1-0.3g	± 0.15-0.5g	± 0.2-0.6g
Size of weighing section	L 300mm*W 120mm	L:350mm*W 120mm	L 400mm*W 120mm
Suitable product size	L≤ 200mm；W≤ 120mm	L≤ 230mm；W≤ 120mm	L≤ 280mm；W≤ 120mm
Weighing Control System	DADI On-line weighing control system V1.1.5
Belt speed	5-90m/min
Sorting section	Standard 2 sections,optional 3 sections
Eliminating device	Air blowing, push rod, baffle, top and bottom turning plate are optional

Product details

Advantage:

1. Weight compensation function

2. Histograms and graphs are used to analyze the product qualification rate.

3. Secondary operation authority management, support self-set password.

4. 100 product formulas can be preset and stored.

5. Multiple rejection methods for unqualified products, and support for unqualified shutdown function.

6.It can be used to eliminate bottles and cans, and to ensure that the bottles do not fall without caps and are sorted to the storage area normally.

Application

Beverage box industry

Product missing inspection For products with small packages in large packages, such as beverage boxes, and large bags containing multiple small bags of products, due to equipment or personnel factors, the product may be missing. Using a checkweigher to check the weight of a large package can ensure that there will be no missing products in the large package.

Fresh food industry

Sort by column automatically classify products with uneven weight. For example, if the manufacturer of split chicken wants to divide chicken legs of different sizes into several weight ranges, they can use checkweighing to automatically weigh each chicken wing, and send the weight signal to the PLC, which drives the corresponding push plate according to the set range Send the chicken wings to the corresponding box to complete the purpose of automatic classification.

Health Products Industry

Final inspection of product weight In the final stage of product production, the weight of the product is re-inspected, and unqualified products are eliminated to ensure that the weight of the products delivered meets the requirements.
